Water-Based Method Separates Zirconium and Hafnium Five Times Better
Oregon State chemists achieved a zirconium-hafnium separation factor of 33 versus the industry's 6-7, using water and a food additive instead of flammable solvents.
By Nathan Brooks4 min read774 words
In brief
- The OSU process achieved a separation factor of 33, versus an industry standard of 6-7.
- Only two U.S. facilities — ATI in Albany, Oregon, and Westinghouse in Ogden, Utah — perform industrial-scale zirconium-hafnium separation.
- Current plants lose roughly 4% of their flammable organic solvent to air pollution each year, using millions of pounds annually.
- The study is published in the Journal of the American Chemical Society (2026), DOI: 10.1021/jacs.6c10597.
- The patented process uses water, thiocyanate ligands, and choline, a common food additive.
Chemists at Oregon State University have patented a water-based process that separates zirconium from hafnium with a separation factor of 33 — roughly five times higher than the industry standard of six to seven. The method replaces millions of pounds of flammable organic solvent with a solution built around choline, an inexpensive, nontoxic chemical commonly used as a food additive.
The research, led by graduate research assistant Alex Roseborough and chemistry professor May Nyman of the OSU College of Science, is published in the Journal of the American Chemical Society (2026; DOI: 10.1021/jacs.6c10597). The university has patented the process.
Why are these two metals so hard to pull apart?
Zirconium and hafnium sit among the most difficult separations on the periodic table. The two elements are chemically near-identical, so much so that the mineral zirconium silicate (ZrSiO4), known as zircon, almost always carries trace amounts of hafnium. Mining zircon is the main economic source of both elements.
Yet high purity is non-negotiable for the industries that need them. Zirconium is vital in nuclear power generation, while hafnium is crucial both for nuclear energy and for semiconductor manufacturing. A metal that is not pure enough simply will not work in a reactor component or a microelectronic device.
Only two facilities in the United States can perform this separation on an industrial scale:
- ATI Specialty Alloys & Components in Albany, Oregon
- Westinghouse Electric in Ogden, Utah
Each plant uses millions of pounds of flammable organic solvent every year.
What is wrong with the current process?
Both plants rely on liquid-liquid extraction, today's state of the art for zirconium-hafnium separation. In this technique, the dissolved metals distribute themselves between two immiscible liquids, one of which preferentially captures one element over the other.
The process works, but at a cost. It is energy-intensive, and roughly 4% of the solvent escapes into the air as noxious pollution, the researchers note. The solvent itself is flammable, adding a safety burden on top of the environmental one.
How does the new water-based method work?
Instead of shuffling metals between two liquids, the Oregon State team turned to precipitation — letting dissolved ions with opposite charges attract each other and form an insoluble solid that simply drops out of solution.
Their aqueous recipe has three ingredients:
- Natural zirconium, carrying its few percentage points of hafnium impurity
- Thiocyanate ligands — small charged molecules that bind to the hafnium and zirconium ions
- Choline, the cheap, nontoxic food additive
The result is the precipitation of hafnium-rich species, leaving purer zirconium behind in solution. The process runs at low energy and involves no organic solvent at all.
To measure how well a separation works, scientists use the separation factor. A value greater than one means separation is possible, and the higher the number, the better the performance. The industry standard for zirconium-hafnium separation sits between six and seven. The OSU process reached a top score of 33.
What did the researchers actually say?
"We describe in atomic-level detail how the separation works and how precipitation-based separations can compete with solvent extraction," Nyman said.
She also pointed to the bigger picture: "We still have questions to answer and milestones to achieve, but these findings are really exciting and impactful, especially as society must move toward more carbon-free and high-density electricity generation, including nuclear energy."
That caveat matters. A separation factor measured in the laboratory does not automatically translate into an industrial process operating at the scale of millions of pounds per year. The team acknowledges open questions and milestones ahead, and scaling up precipitation chemistry to replace an entrenched extraction industry will take further work. Still, the published results show, at the atomic level, that a solvent-free route can compete on performance.
Why does this matter beyond the lab?
The stakes reach into two of the economy's most strategically sensitive sectors. Nuclear power depends on zirconium for reactor components, and hafnium plays a dual role in nuclear energy and semiconductor manufacturing — an industry where supply chains are already tight.
A domestic separation process that avoids flammable solvents, cuts air pollution, and lowers energy demand could ease both the environmental footprint and the supply vulnerability of these critical metals. With only two U.S. facilities currently capable of the separation, a cheaper and cleaner alternative arrives at a moment when demand for nuclear components and advanced electronics continues to grow.
For now, the finding stands as a laboratory-scale proof: a food-additive chemistry, a pinch of thiocyanate, and plain water can outperform a decades-old industrial standard by a factor of five.
