CERN Experiment Sees Gluons Act Collectively at Record-Small Scales

ALICE physicists resolved gluon structures one-quarter the size of a proton and found a J/ψ suppression that nuclear shadowing alone cannot explain, pointing toward gluon saturation.

By Nathan Brooks4 min read838 words

In brief

  1. The ALICE experiment resolved gluon structures as small as 0.2 femtometers, about one-quarter the size of a proton.
  2. J/ψ suppression at the smallest scales showed a statistical significance of about three standard deviations.
  3. The study, published in Physical Review Letters (2026, vol. 137, issue 5), used Run 2 LHC data with lead nuclei.
  4. Measurements covered photon-nucleus energies from 20 to 633 billion electron volts at three resolutions: 0.6, 0.3 and 0.2 femtometers.
  5. Results challenge conventional nuclear shadowing and are consistent with predicted gluon saturation.
CERN finds gluons behaving strangely deep inside atomic nuclei
Plate Nº 43CERN finds gluons behaving strangely deep inside atomic nuclei — AI-generated

Physicists at CERN have measured structures as small as one-quarter of a proton's size inside atomic nuclei — and at that scale, they saw gluon behavior that a long-standing textbook explanation struggles to account for.

The study, published in Physical Review Letters on data from the ALICE experiment at the Large Hadron Collider, reports the first multidimensional measurement of "incoherent" J/ψ photonuclear production, tracking both interaction energy and momentum transfer simultaneously. At the smallest scales probed, J/ψ particle production dropped significantly — a suppression with a statistical significance of about three standard deviations.

University of Kansas physicist Daniel Tapia Takaki, a professor of physics and astronomy and ALICE collaboration member, led the study together with scientists at the Czech Technical University in Prague, an institutional partner of KU.

What are gluons, and why do they matter?

Gluons are the particles that bind quarks together through the strong force, one of the four fundamental forces of nature. Quarks are usually described as the basic building blocks of protons and neutrons. But gluons quietly carry most of the weight of the universe — literally.

"Although quarks are often described as the fundamental building blocks of matter, nearly all the mass of the visible universe — from the atoms in our bodies to the matter inside stars — actually comes from the energy carried by gluons and the strong force that binds quarks together," Tapia Takaki said. "Understanding how gluons behave inside nuclei is therefore essential to understanding how matter itself acquires its mass and structure."

Despite that central role, physicists still do not fully understand how large numbers of gluons behave together inside a nucleus.

How do you turn the LHC into a gluon microscope?

The team used data from Run 2 of the Large Hadron Collider, when fast-moving lead nuclei pass close to one another without directly colliding.

"In these encounters, intense electromagnetic fields surrounding the nuclei behave like beams of high-energy photons," Tapia Takaki explained. "When one of these photons strikes another nucleus, it can briefly produce a particle called the J/ψ, whose production provides a sensitive probe of the underlying gluon structure."

The J/ψ (pronounced "JAY-sigh") serves as the probe. The trick lies in measuring incoherent production, which — unlike many techniques that average the gluon distribution across an entire nucleus — reveals local variations in gluon density. Adjusting the momentum transfer effectively adjusts the microscope's focus.

ALICE probed the nucleus at resolutions of 0.6, 0.3 and 0.2 femtometers. A femtometer is one quadrillionth of a meter. The finest resolution corresponds to structures roughly one-quarter the size of a proton.

To picture that precision: if a nucleus were enlarged to a football stadium, the experiment could distinguish features only a few yards wide on the field.

"Our experiments using incoherent production is like switching from a blurry image to a high-resolution microscope," Tapia Takaki said. "This process allows us to see how gluons fluctuate and organize themselves inside nuclei."

What did the researchers actually see?

The team measured incoherent J/ψ production across photon-nucleus energies from 20 to 633 billion electron volts, and studied how the process varied with momentum transfer.

"The results revealed a striking pattern," Tapia Takaki said. At the smallest spatial scales, J/ψ production was significantly suppressed.

That result is awkward for "nuclear shadowing," a framework that has successfully explained earlier measurements. In that picture, gluons inside a nucleus partially overlap and hide each other, reducing the probability of certain particle production — Tapia Takaki compares it to layers of clouds blocking sunlight. But the new measurements suggest conventional shadowing alone cannot account for the observed pattern.

Instead, the data line up with a phenomenon called gluon saturation, which quantum chromodynamics — the theory of the strong force — predicts.

"In this regime, gluons become so densely packed that they begin interacting strongly with one another, limiting how many can exist in a given region," Tapia Takaki said.

What are hot spots?

Tapia Takaki has helped pioneer this experimental approach and contributed to theoretical models in which gluons cluster into localized regions of especially high density, known as "hot spots." In the energy-dependent version of the model, these dense regions change as collision energy increases. Their behavior could offer signatures of previously unexplored physics of the strong interaction.

The new findings support that broader picture: at extreme scales, the evidence suggests gluons begin to behave collectively.

How solid is the result?

Some caution is warranted. The suppression carries a statistical significance of about three standard deviations — strong evidence by physics standards, but below the five-standard-deviation threshold researchers traditionally treat as a discovery. The measurement is also the first of its kind in multiple dimensions, which means follow-up measurements will be needed to confirm the pattern.

If confirmed, gluon saturation at these scales would give physicists a sharper handle on how the strong force builds the mass and structure of essentially all visible matter — starting from particles most people have never heard of.
