3D-Printed Bioreactor Turns Waste Methane Into Chemicals With 10x Efficiency
LLNL researchers built a 3D-printed solid-state bioreactor that converts waste methane into succinate over 10 times more efficiently than liquid systems, using less power and no heat or pressure.
By James Calloway3 min read662 words
In brief
- The LLNL solid-state bioreactor performs more than 10 times better than conventional liquid-state systems while consuming less power.
- The study was published in Scientific Reports in 2026 (DOI: 10.1038/s41598-026-54237-1).
- The team scaled the reactor from 2 milliliters to 1 liter; real-world deployment requires further scale-up.
- The 3D-printed scaffold uses methanotroph bacteria, which convert methane without added heat or pressure.
- The product, succinate, is used to make polymers, stabilize drugs and enhance food flavor.
A solid-state bioreactor from Lawrence Livermore National Laboratory (LLNL) converts methane into succinate more than 10 times better than conventional liquid-state systems — while consuming less power. The device, described in Scientific Reports in 2026, uses 3D-printed scaffolds filled with methane-eating bacteria to turn a wasted landfill gas into a valuable industrial chemical.
Succinate, the target product, is used to make polymers, stabilize drugs and enhance food flavor. The feedstock — methane released by landfills and wastewater treatment plants — is usually simply burned, losing its value as an energy-rich resource.
How does the bioreactor work?
The method exploits methanotrophs, bacteria that naturally consume and process methane. The LLNL team packed these microbes into a hydrogel that fills the thin lattice walls of a 3D-printed scaffold, replacing the traditional stirred tank.
"These microbes are naturally designed to do the conversion. They work without added heat, without added pressure, without all these things that a chemical process normally requires," said LLNL scientist and study author Samantha Ruelas. "Because it's natural, you don't need those things, and without them, it can be more cost-effective."
Conventional bioprocesses dissolve gas in a water "broth" inside a large vat and stir it vigorously. For poorly soluble gases like methane, this is slow and energy-hungry, which has made methane bioconversion at scale an economic challenge.
The scaffolds solve the problem differently. The hydrogel walls are mechanically robust and resist degradation. The structures hold many times more bacteria than a vat of the same size. And because the walls behave like a thin, porous sponge with high surface area and excellent permeability, methane reaches the microbes quickly. The gas flows directly through and around the scaffold, so there is no need to dissolve it in liquid or stir anything.
"Rather than have this big tank of a 'broth' that you're putting gas into, we produced these thin structures that we call scaffolds," said LLNL scientist and author Nathan Ellebracht.
How was it built and tested?
The project combined LLNL's expertise in biomaterials, additive manufacturing and bioreactor modeling. The team integrated scaffold material selection, printing methods, geometric design and performance modeling into a single workflow.
"LLNL's advanced additive manufacturing capabilities enabled us to integrate the selection of scaffold materials, printing methods, geometric design and performance modeling into a single development workflow," said LLNL engineer and author Hawi Gemeda. Once the optimal design was identified, 3D printing allowed rapid fabrication of prototypes at different sizes, accelerating the move from design to testing and scale-up.
One challenge went beyond geometry. "It was a combination of figuring out how we could engineer our scaffold to maximize our cell density and gas-cell interaction, but also how we keep the cells alive for more than a few days," said LLNL scientist and author Natalie Hwee.
So far, the team has scaled the device from a 2-milliliter reactor to 1 liter. Real-world deployment will require further scale-up, so the results remain at an early, laboratory stage.
Who could benefit?
The reactor's small size could become an advantage rather than a limitation. Large chemical plants only work economically at large scales, while small landfill or wastewater facilities lack good options.
"At smaller landfill or wastewater treatment facilities, there aren't really good, existing solutions that scale down," said Ellebracht. "Our approach could be applied at a small plant and allow them to get value out."
What comes next?
The scaffold concept may extend beyond methane. Qian notes that most industrial bioproduction relies on aerobic sugar fermentation, where oxygen mass transfer remains a major bottleneck, and that immobilizing the biocatalyst would eliminate the downstream step of separating it from the products. "We are now actively extending the solid-state bioreactor concept to other bioprocesses," she said.
Publication: Samantha Ruelas et al., "Solid-state bioreactors for efficient energy recovery from gaseous waste streams," Scientific Reports (2026). DOI: 10.1038/s41598-026-54237-1.
